Compression |
H.264 Compression |
Recording mode |
Real-time recording, Timer, alarm, motion detection & manual |
USB Port |
USB Port for backup to flash drive or USB hard drive |
Remote viewing (TCP/IP) |
Internet Explorer & Mobile phone surveillance - WinCE & Symbian on 3G |
DHCP Network |
Supports DHCP for network setup |
Viewing Features |
Supports multiple channel viewing and backup |
Bandwidth Features |
Supports dual stream for easier internet access with lower bandwidth |
Triplex technology |
Triplex technology (record, playback, connect via network at the same time) |
Hard Drive |
250GB Hard drive, 7200 RPM (pre-installed) |
Video input / output |
4 Channel video input / 2 Channel BNC video output |
Audio input / output |
4 Channel audio input / 2 Channel output |
Display Mode |
Display Resolution: 704x480 & Auto switch, full screen, quad, 16 screen |
Record Resolution |
352x240 at 120FPS, and 704x480 at 30FPS (shared by cameras) |
Operating System Support |
Software Operating System Support: Windows 2000, XP, Vista |
PTZ Support |
RS-485 Port (PTZ Support): Yes |
Network Features |
10/100 Fast Ethernet Network |
Power Supply |
DC 12 V |
Operating Temperature |
5°C to 70°C (41°F to 158°F) |
Input Device |
USB mouse |
Remote |
Remote control with batteries |
Camera Spectications |
Camera Spectications |
. |
8 color CCD ¼” Sony camera with night vision 30 ft. Night vision 12 IR LEDs |
Built-in lens: |
4 cameras w/3.6 mm, & 4 cameras w/6 mm |
. |
8 x 60 feet cables |
Infrared wavelength: |
850 nm |
. |
8 x Camera power supply |
Lighting distance: |
10 m 30 ft. Night vision |
Horizontal resolution: |
420 TV lines |
. |
Use indoor or outdoor |
