Video Compression |
H.264 |
Video System |
NTSC / PAL |
Operation System |
Linux |
Audio Compression |
8kHz x 16bit ADPCM |
Audio Input / Output |
BNC 4 Channel Inputs / 2 Channel Outputs |
Intercom Input |
BNC 1 Channel |
Monitoring Resolution |
PAL: D1(704x576) / NTSC: D1(704x480) |
Playback Resolution |
PAL: CIF(352x288) / NTSC: CIF(352x240) |
Display Frame Rate |
PAL: 400fps / NTSC: 480fps |
Total Recording Frame Rate |
PAL: 400fps@CIF / NTSC: 480fps@CIF |
Recording Mode |
Always / Schedule / Motion Detection / Sensor Triggered |
Display Mode |
Single / Quad / Nine / Hex / PIP / S.E.Q. |
Recording Pack Time |
15/30/45/60mins Selectable |
HDD Port |
Support Up to 2 Sets of SATA HDD 1 TB HDD installed |
Network Interface |
RJ45, 10M/100M |
Network Protocol |
Support TCP/IP, UDP, DHCP, DNNS, PPPoE |
Network Function |
IE Viewer / Live Monitoring / DVR Setting / Mobile Phone Email Function |
Mobile Phone Function |
Support Symbian S60 3rd Edition System / Windows Mobile |
USB2.0 |
1 USB Mouse, 1 USB Backup Device |
Playback |
Local: Max. 4 Ch. At the Same Time Network: 1 Ch. At The Same Time |
PTZ |
Built-in RS-485 Port, Support PELCO-P PELCO-D |
Backup |
USB Flash Disk, Removable HDD, USB CD/DVD-RW, Network |
Alarm Mode |
Motion Detection, Sensor Triggered, Video Loss, HDD Error, HDD Full |
Senor Alarm I/O |
16 Sensor Inputs / 1 Alarm Output |
CD/DVD-RW |
Optional |
Power Supply |
DC 12V/5A (Power Adaptor Included) |
Working Temperature |
10C ~ 40C |
Working Humidity |
10% ~ 90% |
Playback Mode |
Normal Play, Fast Forward, Fast Rewind, Manual |
Security Features |
Security Features |
• |
Support remote view with Mobile Phone(Symbian S60 3rd system Windows mobile system) & real-time remote view with IE (Internet Explorer).. |
• |
H.264 real-time high compression, support dual stream network transmission; plus transmit audio via network. |
• |
Remote Alarm Notification via Email Images. |
• |
Support up to 2 x 1TB SATA HDDs.. |
Sale Price: |
$750.00 |
