Image Sensor |
1/4" Color Progressive CCD |
Lens |
Basic Lens included (will take Yours):500mm to infinity; Angle of View: 60° |
Iris Operation |
Auto (requires auto iris lens) |
Minimum Illumination |
0.4 Lux (F1.7) |
Built-In Microphone |
Yes |
Controls |
Brightness,Contrast,4x Digital Zoom,IR Cut Filter,AWB,AES, & Bandwidth. |
Alarm I/O |
2 Alarm inputs, 2 alarm outputs |
Control Port |
RS-485 |
Wireless Specitications |
Wireless Specitications |
Wireless Standard |
802.11 b/g, 1x2 MIMO |
Antenna |
2 Antennas |
Network |
Network |
Compression Format |
Simultaneous MPEG-4/MJPEG |
Supported Protocols |
TCP/IP, HTTP, DHCP, SMTP, FTP, NTP, DNS, UPnP, RTP, RTSP and DDNS |
Picture Size |
640 x 480 (VGA), 320 x 240 (QVGA), 160 x 120 (QQVGA) |
Frame Rate |
1 to 30 FPS (Selectable) |
Simultaneous Client Access |
Yes |
Multiple Camera Views |
Up to 16 (using included software) |
Motion Detection |
4 Detection Areas with Individual Sensitivity |
Network Interface |
802.11 b/g Wireless, RJ-45 |
System Requirements |
System Requirements |
. |
• Wired Ethernet or Wireless 802.11b/802.11g Network |
. |
• Network Adapter With Ethernet Network Cable and TCP/IP Installed Per PC |
. |
• Switch/Router To Support Multiple Connection Points |
. |
• Internet Explorer 5.x or above with ActiveX Support for Viewing |
. |
• Microsoft Windows Vista, XP, 2000, ME or 98SE |
. |
• 2 GHz Pentium 4, or AMD Athlon Class CPU with 512 MB RAM |
. |
• 128 MB AGP Video Adapter |
General |
General |
Power Requirements |
12 VDC (includes 110-120 VAC adapter) |
Power Consumption |
10W |
Operating Temperature |
32 - 122°F (0 - 50°C) |
Dimensions (WxHxD) |
3 x 1.8 x 4.7" (76 x 46 x 120mm) |
Weight |
1.2 lbs (0.5 kg) |
. |
. |
